Stair Data
|
Specification
|
Data
|
Specification
|
|
Floor to floor height
|
Customized based on your job site
|
Beam Thickness
|
10/12/5+5/6+6mm
|
|
Step Lenghth
|
900-2000mm
|
Step Width
|
250-350mm
|
|
Step Height
(Riser)
|
150-200mm
|
Stairwell size
|
no less than 3500mm for curved stairs
no less than 1300mm for spiral stairs |
|
Components
|
Dimensions
|
Material
|
Surface
|
|
Stringer/
Beam |
150*150*6mm/ 100*200*6mm/ 300*12mm/ 300*(6+6)mm
|
A3 steel; SS304/316
|
Powder coated; Satin or mirror finish
|
|
Center Post
|
104/108/114*4mm for spiral stair
|
A3 steel; SS304/316
|
Powder coated; Satin or mirror finish
|
|
Tread
|
length: Customized
width: 250-300mm thickness: 30mm solid timber；25.52mm laminated tempered glass；30mm solid marble. (38mm solid wood / 10+10mm / 12+12mm laminated glass for spiral stair) / Customized |
Timber, Glass, Marble, Granite
|
Painting, Frosted, Clear,Polished
|
|
Tread Support
|
50.8*50.8*4mm/38*38*4mm square tube / 6mm steel plate
|
A3 steel; SS304/316
|
Powder coated; Satin or mirror finish
|
|
Balustrade
|
12mm glass railing/ stainless steel, 10/12mm glass railings/ stainless steel railing/ customized
|
tempered or laminated glass；A3 steel; SS304/316
|
Clear, satin or mirror
|
|
Handrail
|
50.8*1.35mm handrail or slot handrail, 38/50.8*1.2mm/ slot handrail/ customized
|
A3 steel; SS304/316; solid timber; PVC handrail.
|
satin or mirror or powder coated
|
